AGFRC A50CHM SERVO PURCHASE LINK
If you are a drift car enthusiast, you must not miss this low profile programmable servo A50CHMW that can be used in 1/10 1/12 Drift cars, On road, Racing cars, Racing Boat, Plane, etc. It has a high voltage of 8.4V, and the maximum torque can reach 18KG. The CNC aluminum smooth casing is not only small in size, light in weight, but also highly accommodating. It can be your reliable partner even in rainy, humid environment training or competition. Because IP67 magnetic waterproof function is essential, which unlocks more usage environments for many enthusiasts. In addition, It features strong steel gears, titanium gears designed to work perfectly with silky dual bearings and a high quality coreless motor.
Ideal For 1/12, 1/10 On Road, Boat, Airplane etc.
FEATURES
• High Performance Low Profile Digital Servo
• High Precision Magnetic Sensor
• High Precision Steel Gear
• High Efficiency Coreless Motor
• Reliable Silky Dual Ball Bearing
• Aluminum Top And Middle Part
• Programmable Digital Circuit
PRODUCT SPECIFICATIONS
Voltage4.8V ~ 8.4V DirectionCCW
Gear MaterialStrength Steel Temperature-15°C ~ +70°C
Pulse Width500 ~ 2500 µSec Refresh Rate1520 µS / 333Hz
Dimension40.8*20.2*26.5 mm Motor TypeBrushless
Bearing2BB Dead Band2 µSec
Net Weight50.0 g Gear Spline25T-ɸ5.92 mm
Case MaterialAL6061T6 Travel Angel180 ± 10°
WireJR 180mm / 22AWG Wire ColorBlack | Black | Grey
Operating Speed Stall Torque
0.140 sec/60° @4.8V 11.0 kg·cm (153 oz·in) @4.8V
0.130 sec/60° @6.0V 13.0 kg·cm (181 oz·in) @6.0V
0.120 sec/60° @7.4V 16.0 kg·cm (222 oz·in) @7.4V
0.110 sec/60° @8.4V 18.0 kg·cm (250 oz·in) @8.4V
